Svantek SV104-IS Noise Dosimeter (Intrinsically Safe)

Svantek SV104-IS Noise Dosimeter (Intrinsically Safe)

Youtube video (10:09) on SV104 noise dosimeter operation.

The SV 104IS is the intrinsically safe version of the revolutionary personal noise dosimeter, the SV 104. Both instruments offer a new approach to occupational health and safety noise monitoring presenting features such as 1/1 octave band real-time analysis and audio events recording functions which are a new quality in an instrument of this size. All results are clearly displayed on the amazing OLED screen which offers excellent visibility even in full daylight or darkness.

This personal dosimeter has a robust 1/2" MEMS microphone enabling easy calibration using most commonly available acoustic calibrators. The new microphone has a large dynamic range of the 90 dB which allows to measure noise from 60 dBA to 140 dBA. The long list of microphone advantages includes also the auto calibration feature and TEDS memory that stores the calibration info in the microphone itself. The auto-calibration means performing the acoustic calibration automatically once the microphone is inserted into the calibrator.

The SV 104IS is a cable-free dosimeter and is typically attached to the user’s shoulder, close to the ear using the mounting clips supplied. The instrument works with Svantek’s health and safety software package, “Supervisor”, that provides various tools for data analysis and reporting. The docking station supports data transfer to the PC through the infrared interface as well as handles the battery charging. Rechargeable batteries of SV 104IS are able to power the instrument for 50 hours.



Video

The story of SV104 noise dosimeter



For the relationship between Leq and Dose, click here.



Email us at sales@aisys.com.sg for more information, or call us at +65 62968012 .

Features

  • Intrinsic safety in accordance to ATEX and IECEx
  • Personal Noise Dosimeter conforming to IEC 61252 and ANSI S1.25
  • Class 2 in accordance to IEC 61672
  • Measurement range 60 dBA RMS ÷ 140 dBA Peak
  • L(C-A) calculation
  • Automatic calibration start (auto-calibration)
  • Shock resistant MEMS microphone
  • Built-in tri-axial accelerometer for vibration shock (knocking) detection
  • High contrast colour OLED display
  • Single measurement range
  • Option for octave real-time analysis
  • Option for audio events recording
  • Voice tagging
  • Three virtual measurement profiles
  • Operational time > 50 hours
  • Rechargeable battery
  • Extremely compact, light weight and robust case



Specification

  • Standards  :  IEC 61252 ed1.1 (2002); ANSI S1.25-1991 (R2007); Class 2 IEC 61672-1 ed2.0 (2013); ATEX: EN 50303, EN 60079-0, EN 60079-11, EN 60079-26, ;certificate number: FTZU 14 ATEX 0055X; IECEx: IEC 60079-0, IEC 60079-11, IEC 60079-26, certificate number IECEx FTZU 15.0001X
  • Weighting  :  Filters A, C and Z
  • Time constants  :  Slow, Fast, Impulse
  • Exchange rates  :  2, 3, 4, 5, 6
  • Measurement results  :  Run Time (TIME), Lpeak, Lmax, Lmin, L, DOSE (%), Projected Dose D_8h, Projected Dose PrDOSE, Leq, LAV, LE, SEL8, E, E_8h, LEPd, PSEL, Ltm3, Ltm5, Ln statistics, Peak Threshold Counter (PTC), PTP, Upper Limit Time (ULT), TWA, Projected TWA (PrTWA), Lc-a, OVL
  • Measurement profiles  :  3
  • Microphone  :  Class 2 microphone, 1/2" housing with built-in TEDS functionality for the automatic calibration
  • Measurement range  :  60 dBA RMS ÷ 140.1 dBA Peak
  • Frequency range  :  20 Hz ÷ 10 kHz
  • Dynamic range  :  90 dB
  • Data logging  :  Summary results for the measurement time; Time-history logging of Leq/Max/Min/Peak with 1s logger step
  • Voice comments  :  Audio records on demand, created before or after measurement, added to measurement file
  • Audio recording  :  Short audio events recording on trigger, 12 kHz sampling rate (option); 1/1 octave Real-time analysis in octave band filters, Class 1, IEC 61260; 9 filters with centre frequencies from 31.5 Hz to 8 kHz (option)
